RAVENOL ATF Fluid Type F

Category: Gear oil for automatic transmissions
Item number: 1213105
Oil type: Mineral
Application: Passenger car, Oldtimer

RAVENOL ATF Fluid Type F is a universal ATF (automatic transmission fluid) for use as specialty transmission oil for Ford, BorgWarner and Volvo.

RAVENOL ATF Fluid Type F is designed based on refined base oils with a special additive treatment and inhibition ensuring trouble-free function.

Application Note

RAVENOL ATF Fluid Type F is suitable for use as speciality transmission oil for Ford, Borg Wagner and Volvo.

Use RAVENOL ATF Fluid Type F according to aggregate manufacturer operating instructions in: Automatic transmissions, fluid turbo coupling, servo clutches and other hydrostatic and hydrodynamic systems.

Characteristics

  • Universal use, therefore minimising the risk of confusion and making stock-keeping easy.
  • Good lubricating ability even in low temperatures during winter.
  • Stable lubricating film under extreme stress in midsummer resulting in comparatively low wear throughout the change interval.
  • Excellent viscosity-temperature properties.
  • High thermal resilience.
  • Non-foaming even in extreme conditions.
  • Reliable protection against wear, sludge, corrosion and adhesion.
  • FZG test: Reaches failure load stage 12 before and after shearing.

Technical Product Data

PropertyUnitDataAudit
Density at 20 °Ckg/m³848,0EN ISO 12185
ColourrotVISUELL
Viscosity at 100 °Cmm²/s7,3DIN 51562-1
Viscosity at 40 °Cmm²/s34,3DIN 51562-1
Viscosity Index VI185DIN ISO 2909
Pourpoint°C-45DIN ISO 3016
Flashpoint°C210DIN EN ISO 2592

All indicated data are approximate values and are subject to the commercial fluctuations.
