RAVENOL ATF MERCON® V

Category: Gear oil for automatic transmissions

Item number: 1212101

Specification: MERCON® V

Oil type: Synthetic

Approvals: MERCON® V (Lizenznummer M5060502)

Recommendation: Ford 8000045, Ford ATF E-M5, Ford WSS-M2C202-B, Ford WSS-M2C919-E, Ford XT-5-QMC, Ford 1565889, Ford 5014519, Ford XT-5-5QM, Ford XT-5-DMC

Application: Passenger car

RAVENOL ATF MERCON® V is a synthetic ATF (Automatic Transmission Fluid), designed on the basis of high quality hydrocrack oils with a special additive and inhibition, which ensure a perfect function of the automatic transmission.

RAVENOL ATF MERCON® V guarantees a maximum of corrosion protection during any operating condition.

RAVENOL ATF MERCON® V is a ATF (Automatic Transmission Fluid ATF for automatic transmissions of FORD.

Application Note

RAVENOL ATF MERCON® V was especially developed for the use in automatic transmissions of FORD. It is recommended to flush with RAVENOL ATF MERCON® V before filling.

Characteristics

a very good lubricating ability even at low temperatures in winter
a high, stable viscosity index
a very low pour point
a very good oxidation stability
as far as possible protection against corrosion and foam formation
good balanced coefficient of friction
neutral behaviour against sealing materials
neutral behaviour because of inhibition against non-ferrous metals

Technical Product Data

Property	Unit	Data	Audit
Density at 20 °C	kg/m³	847,0	EN ISO 12185
Colour		rot	VISUELL
Viscosity at 100 °C	mm²/s	7,2	DIN 51562-1
Viscosity at 40 °C	mm²/s	34,8	DIN 51562-1
Viscosity Index VI		178	DIN ISO 2909
Brookfield Viscosity at -40 °C	mPa*s	15.800	ASTM D2983
Pourpoint	°C	-48	DIN ISO 3016
Flashpoint	°C	210	DIN EN ISO 2592

All indicated data are approximate values and are subject to the commercial fluctuations.
