Category:
Gear oil for manual transmissions and drive axis
Item number:
1250055
Viscosity:
80W-90
Specification:
API GL-4
Oil type:
Mineral
Application:
Motorcycle
RAVENOL MOTOGEAR SAE 80W-90 GL-4 is a transmission fluid on a mineral oil basis with special effective additives for manual transmissions. A high load-carrying capacity guarantees optimum gearbox lubrication even at high temperatures.
RAVENOL MOTOGEAR SAE 80W-90 GL-4 ensures a strong oil film for lubrication even under the most extreme dynamic conditions.
RAVENOL MOTOGEAR SAE 80W-90 GL-4 reduces friction, prevents wear and corrosion.
Application Note
RAVENOL MOTOGEAR SAE 80W-90 GL-4 is suitable for use in manual transmissions for 2- and 4-stroke motorcycles if oil according to SAE 80W-90 API GL-4 is specified.
Characteristics
- Highly adhesive and pressure resistant lubricant films
- Excellent oxidation stability
- Above-average viscosity-temperature characteristics
- Wear-preventing effect
- A good air release property, no foaming
- Neutral behaviour towards metal and sealing compounds
Technical Product Data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Density at 20 °C | kg/m³ | 879,0 | EN ISO 12185 |
| Colour | gelbbraun | VISUELL | |
| Viscosity at 100 °C | mm²/s | 14,0 | DIN 51562-1 |
| Viscosity at 40 °C | mm²/s | 126,9 | DIN 51562-1 |
| Viscosity Index VI | 108 | DIN ISO 2909 | |
| Brookfield Viscosity at -26 °C | mPa*s | 45.600 | ASTM D2983 |
| Pourpoint | °C | -33 | DIN ISO 3016 |
| Flashpoint | °C | 244 | DIN EN ISO 2592 |
| Copper Strip Test at 121 °C | 1b | ASTM D130 |
All indicated data are approximate values and are subject to the commercial fluctuations.
